Wire type and power, AC 2-wire type 100-240VAC~ ; Sensing side diameter, M18 ; Sensing distance, 5mm ; Installation, Flush ; Standard sensing target, 18×18×1mm(iron).
- Sensing side diameter : M18
- Sensing distance : 5mm
- Installation : Flush
- Standard sensing target : 18×18×1mm(iron)
- Response frequency : 20Hz
Specifications
| Wire type and power | AC 2-wire type 100-240VAC~ |
|---|---|
| Sensing side diameter | M18 |
| Sensing distance | 5mm |
| Installation | Shield(flush) |
| Standard sensing target | 18×18×1mm(iron) |
| Response frequency | 20Hz |
| Current specification | Leakage current: Max. 2.5mA |
| Control output | Normally Closed |
| Material | Brass(nickel plated) |
| Cable Standard/material | Standard cable |
| Protection structure | IP67 |
| Body length | Standard type |
| Environment_Ambient temperature | -25 to 70℃, storage: -30 to 80? |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Residual voltage | Max. 10V |
| Insulation type | Double insulation or reinforced insulation(mark:Â , dielectric strength between the measuring input part and the power part: 1kV) |
| Weight | Approx. 130g(approx. 118g) |
